VCOM Import - Webdyn

    Technical details

    Protocol

    ftp

    File format

    csv

    Reporting interval

    variable / 300 seconds (recommended)

    Server

    FTP (please see FTP access data)

    Port

    21


    Datalogger setup in VCOM

    • Create a new datasource in VCOM and select device type Webdyn
    • Insert correct datalogger serial number and choose local recording interval settings


    Setup datalogger

    Communication

    • Please make sure that all datalogger assigned to one system in VCOM use the same recording interval to ensure that charts work properly
    • Copy given FTP access data in VCOM setup and insert it into datalogger setup
    • Perform communication test

    General setup

    \CONFIG\*_daq.ini

    DAQ_Period=5

    DAQ_PeriodSec=0

    DAQ_HeaderOption=1

    ..

    ..

    MODBUS_Addr[0]=1

    MODBUS_Name[0]=Inverter_Growatt

    MODBUS_FileDefName[0]=growatt_60kw.ini

    MODBUS_Addr[1]=2

    MODBUS_Name[1]=Secure_Elite_300

    MODBUS_FileDefName[1]=Secure_Elite_440_446.ini

    MODBUS_Addr[2]=3

    MODBUS_Name[2]=3-in-1 sensor

    MODBUS_FileDefName[2]=Modbus_IMT_Sensor.ini

    …

    …

    <- must be 1

    …

    …

    …

    ...

    <- necessary folder for device config (modbus)

    ...

    …

    <- necessary folder for device config (modbus)

    ...

    …

    <- necessary folder for device config (modbus)

    CONFIG/*_config.ini

    ID=704-01

    IDFile_Enable=0

    INV_Type=0

    INV_Name=INV

    <- shows serial number, must be inserted in VCOM datalogger configuration


    Folder structure for device config files


    /DEF/INV/
    /DEF/IO/
    /DEF/MODBUS/growatt_60kw.ini
    /DEF/MODBUS/Secure_Elite_440_446.ini
    /DEF/MODBUS/ Modbus_IMT_Sensor.ini
    /DEF/TIC/

    Folder structure for data files


    /DATA/ID/
    /DATA/INV/
    /DATA/IO/
    /DATA/MODBUS/WD*.csv.gz
    /DATA/TIC/

    How to adapt meter scale factor

    If necessary the scale factor can be adapted in the meter config file, in our example the file is called "Secure_Elite_440_446.ini":

    ...
    Modbus_VariablesTables={
    # Description des champs
    # varIndex;varReqIndex;varName;varType;varSigned;varPosition;varOption1;varOption2;varCoeffA;varCoeffB,varUnit,varAction;6
    ...

    19;19;3 phase active power;8;2;1;;;1;0;kW;4

    20;20;R phase reactive power;8;2;1;;;1;0;kVAR;4
    21;21;Y phase reactive power;8;2;1;;;1;0;kVAR;4
    22;22;B phase reactive power;8;2;1;;;1;0;kVAR;4
    23;23;3 phase reactive power;8;2;1;;;1;0;kVAR;4
    24;24;R phase apparent power;8;2;1;;;1;0;kVA;4
    25;25;Y phase apparent power;8;2;1;;;1;0;kVA;4
    26;26;B phase apparent power;8;2;1;;;1;0;kVA;4
    27;27;3 phase apparent power;8;2;1;;;1;0;kVA;4
    28;28;Frequency;8;2;1;;;1;0;Hz;4
    29;29;Active Total import;8;2;1;;;1;0;kWh;4

    30;30;Active Total Export;8;2;1;;;1;0;kWh;4
    .....

    The factor can be changed in the 9. column "varCoeffA":

    Example active power
    19;19;3 phase active power;8;2;1;;;1;0;kW;4
    change factor from 1 to 0.001 (for conversion from W to kW)
    19;19;3 phase active power;8;2;1;;;0.001;0;kW;4

    Example active energy
    30;30;Active Total Export;8;2;1;;;1;0;kWh;4
    Change factor from 1 to 0.001 (for conversion from Wh to kWh)
    30;30;Active Total Export;8;2;1;;;0;0.001;kWh;4
